Vantec 1x M.2 NVMe SSD PCIe X4 Adapter with ARGB Aluminium Heatsink – Addresable LED RGB lighting compatiable with Asus Aura, MSI Mystic Light, Gigabyte Fusion. M.2 Type Support: NVMe using M Key (PCIe 3.0×4) or NVMe using B+M Key (PCIe 3.0×2); M.2 size: Length support 22×80, 22×60, 22×42, 22x30mm.

Product Overview

The Vantec UGT-M2PC12-RGB M.2 NVMe PCIe x4 Adapter features an ARGB heat sink for enhanced cooling and stylish lighting. It supports M.2 NVMe modules of various lengths (30mm to 80mm) and ensures fast data transfer via PCIe x4 lanes. Compatible with multiple operating systems, it provides efficient heat management and seamless performance for high-speed storage solutions.

Features

-Addressable 5V RGB LED
-Heat Sink Full Coverage to Protect NVMe
-Support M.2 NVMe Module like 80, 60, 42, 30mm
-Fast PCl Express v4.0/v3.0 Specs to NVMe via PCle x4, x8, or x16 slot
-Support Booting with Latest UEFI System Boards and OS
-Standard and Low Profile Bracket included
-Compatible with any OS including Windows, Linux
-Support M.2 Interface with NVMe M Key (PCle 3.0×4) or NVMe B+M key (PCle3.0x2)
-Uses Minimum power from PCle 3.3v for better power management

System Requirements
-Available system board PCle x4 or x8 or x16 slot
-Optional: 5V RGB header (3-pin)
-OS support like Windows 7/8/8.1/10/, or Linux
-For booting, requires UEFI System Board and latest OS

Specifications

-Product Code: UGTM2PC12-RGBADP
-Description: Vantec 1x M.2 NVMe SSD PCIe X4 Adapter with ARGB Aluminium Heatsink
-M.2 Type Support: NVMe using M Key (PCle 3.0×4) or NVMe using B+M Key (PCle 3.0×2)
-M.2 size: Length Support 22×80, 22×60, 22×42, 22x30mm
-Internal Interface: 1xM.2 (NGFF),M Key
-PCle Interface: PCle v4.0/v3.0/v2.0x4 (4 lanes)
-Power: PCle Bus powered (3.3v)/RGB Powered
-Dimensions: 4.7×2.5×0.6 inches/120x62x16mm
-Weight:5.1 oz / 146 g
-RGB Cable length: 19.7 Inches /500mm
-RGB Header: 5V ARGB, 3-pin hearder
-RGB Specs Suport: Asus Aura, MSI Mystic Light, Gigabyte Fusion
-OS support: Windows 7/8/8.1/10, or Linux
